Iris Diaphragm Manufacturing and Inspection

A visual record of iris mechanism assembly, component preparation, aperture movement and dimensional inspection at our Ningbo factory.

Worker assembling iris mechanisms at a bright factory workbench with components arranged around the station

Factory iris assembly workbench

Iris mechanisms and components arranged around a manual assembly station.

Gloved hands positioning black iris blade-mechanism components on a gray workbench

Iris blade assembly close-up

Gloved hands positioning blade-mechanism components during assembly.

Five iris mechanism components aligned horizontally on a light gray industrial workbench

Iris mechanism components

Five components aligned horizontally for a clear component-level view.

Three iris mechanisms arranged side by side with open, intermediate and nearly closed apertures

Aperture opening comparison

Three iris mechanisms shown at open, intermediate and nearly closed positions.

Digital caliper displaying 20.02 mm while a black iris component is measured by gloved hands

Caliper dimensional inspection

The display shows 20.02 mm in this inspection example; it is not a universal product specification.

Twelve curved black iris blades arranged in a four-by-three array on a gray workbench

Twelve iris blades arranged for inspection

Twelve curved blades arranged on a gray inspection surface.

01

A conservative process.

Step 01

Requirement review

The project requirement is reviewed before any component work begins.

Step 02

Component preparation

Component-preparation requirements are defined for the selected design.

Step 03

Assembly

Iris blade mechanisms are assembled according to the reviewed requirement.

Step 04

Dimensional and movement checks

Finished dimensions and aperture movement are checked against the agreed specification.
